К-т за зацепване на бензинови и дизелови двигатели на VAG VW, AUDI, SKODA, SEAT - ZT-04772 - SMANN PROFESSIONAL

К-т за зацепване на бензинови и дизелови двигатели VAG-VW,AUDI, SKODA,SEAT, - ZT-04772 - SMANN TOOLS.

Приложение:
Audi:A4, A6, A8, 80 - A2 - A3 - S3 - A4 - A6 - TT;
VW: Passat (98-04);Bora, Caddy, Fox, Golf, Lupo, New Beetle, Passat, Polo, Sharan, Touran;
Seat: Alhambra, Arosa, Cordoba, Ibiza, Inca, Leon, Toledo
Skoda: Fabia, Octavia (from 96)
Бензинови двигатели:1.2 6V - 1.2 12V - 1.4 - 1.6 - 1.8 - 1.8T - 2.0 16V ;
Дизелови двигатели:1.2, 1.4, 1.9, 2.0 TDI PD 1.7, 1.9 D / TD / SDI / TDI 2.5 V6 TDI;
Кодове на двигателите:
AFB, AKE, AKN, AYM, BAU, BCZ, BDG, BDH, BFC,
ОЕМ кодове на инструментите:
T10265, T10264, T10120, T10060/T10060A, 3418, 3366, 3458, T10100, T10123,
T10120, 3242,T10098A, T10016, 3078, 2064, 3359, T10008, 3369, 3359, T10020,
T10092, T40011, 2065A, 10050,

THIS NEW KIT OF TWELVE TOOLS IS REQUIRED FOR PETROL AND DIESEL ENGINE SERVICE INCLUDING
TIMING BELT REPLACEMENT ON RECENT MODELS AND ALSO OLDER 1.9D MODELS FPOM 1976.MODELS:

AUDI: A4, A6, A8, A11yoad(97-04)
VW: PASSAT: (98-04)
ENGINES CODES: AFB, AKE, AKN
AYM, BAU, BCZ, BDG, BDH, BFC.

Audi VW Engine Belt Adjust Locking Timing Tool Kit VAG Petrol Diesel Set 97-08

Diesel engines:
1.2 , 1.4 , 1.9 , 2.0 TDI PD, 1.7 , 1.9 D / TD / SDI / TDI, 2.5 TDI V6
Audi: 80, A2, A3, A4, A6, Cabriolet ( 95-00 )
Seat: Alhambra, Arosa, Altea, Cordoba, Ibiza, Inca, Leon, Toledo
Skoda: Fabia, Felicia, Octavia ( 93-05 )
VW: Bora, Caddy, Golf, Lupo, New Beetle, Passat, Polo, Sharan, Transporter, Touran

Petrol engines:
1.2 6V - 1.2 12V - 1.4 - 1.6 - 1.8 - 1.8 T - 2.0 16V
Audi: 80 - A2 - A3 - S3 - A4 - A6 - TT
Seat: Alhambra, Arosa, Cordoba, Ibiza, Inca, Leon, Toledo
Skoda: Fabia, Octavia (from 96)
VW: Bora, Caddy, Fox, Golf, Lupo, New Beetle, Passat, Polo, Sharan, Touran
Lock mandrel and angle screwdriver (SW6) for timing belt tensioner
with 4-cylinder Diesel engines, eg VW Golf, Caddy, Sharan, Touran from 2004
Locking for camshaft timing chain and timing belt tensioner,
for gasoline engines 1.8 , 1.8 t (double camshaft), 2.4 , 2.7 , 2.8 (V6)
eg: Audi A3, A4, A6, TT
Seat Alhambra, Cordoba, Ibiza, Leon, Toledo
Skoda Octavia

Content from the trailer:

    1. camshaft adjustment gauge - for 1.9 LD / SD / SDI / TD / TDI (from 97), not for pump-nozzle, also suitable for Ford and Volvo VW OE comparison number 3418

    2. Locking - for camshaft and crankshaft at 2.5 L TDI V6 and 3.3 L V8 TDI (Audi A8) VW OE comparison number 3458

    3. lock mandrel for crankshafts - for V6 / V8 Diesel VW OE comparison number 3242

    4. Stop mandrel - to fix the tensioner for timing belt change

    5. lock mandrel - to lock the injection pump sprocket at 1.9 LD / SD / SDI / TD / TDI and the camshaft at TDI pump-jet engines VW OE comparison number 3359

    6. Locking - to lock the oval crankshaft toothed belt wheel with 2.0 L TDI pump nozzle VW OE comparison number T 10100

    7. Timing Belt Spanner Wrench - flexible head with locking screw, thus well suited for cramped spaces (functions of the following keys idler V 159 , 3387 and T 10020 )

    8. Unscrew the screw securing the fan clutch

    9. camshaft adjustment gauge - fixed the camshaft and pump shaft when replacing a timing belt and installation of injection pump VW OE comparison number 2065 A

    10. Locking - to lock the crankshaft belt pulley at 1.2 / 1.4 L / 1.9 L TDI pump nozzle VW OE comparison number 10050

    11. lock mandrel - to fix the tensioner when replacing a timing belt VW OE comparison number T 40011

    12 studs - relieves the belt tension by pressure build-up on the plunger on the drive belt tensioner OE VW comparison number T 10092

    13. Support rods - to advance the front wall to the engine VW OE comparison number 3369

    14. lock mandrel - for TDI pump nozzle VW OE comparison number 3359

    15 Retaining plate - to lock the tensioner timing belt on TDI pump nozzle VW OE comparison number T 10008

    16. Locking device - Camshaft 1.4 / 1.6 L 16V petrol engines VW OE comparison number T 10016

    17 lock mandrel - to lock the injection pump sprocket VW OE comparison number 2064

    18. camshaft adjustment gauge - to lock the camshaft on 1.9 L TDI and SDI, disassembly of the valve cover is not required VW OE comparison number T 10098 A

    19. Locking - for camshaft and crankshaft when changing the timing chain on the 1.2 L 12V 3-cylinder engine VW OE comparison number T 10123

    20. 12-kt. Diesel -Einspritzdüsen, SW22 VW OE comparison number 3078

    21. fixing bolt for locking the crankshaft when checking the timing VW OE comparison number T 10120

    22 holder for chain tensioner for installation and removal of the chain tensioner VW OE comparison number 3366

    23 Absteckdorn 4, 7 and 8 mm

    24 locking the tensioner roller for removing and installing the timing belt on vehicles with modified engine mounts VW OE comparison number T 10264

    25. actuation of the clamping role in removal and replacement of the timing belt on vehicles with modified engine mounts VW OE comparison number T 10265

    26. For injection and Diesel engines for locking the clamping element in disassembly of the V-ribbed belt. VW OE comparison number T 10060 / T 10060 A

    27. Locking - for camshaft and crankshaft when changing the timing chain on the 1.2 L 12V 3-cylinder engine VW OE comparison number T 10120

    28 Absteckdorn

    29 incl. System case

Technical info:

    Changing the timing belt, crank and Nockenwellenarretierwerkzeug
    for the professional repair of VAG engines

 Suitable for motors with the following engine codes:
 AFB / AKE / AKN / AYN / CONSTRUCTION / BCZ / BDG / BFC
